series 41

flange connection DN50 – DN150 (DIN PN 10/16)

material specifications

housing, not in contact with medium:
aluminium casting G-Al Si 7 Mg, age-hardened, powder-coated silver-grey
o-ring:
nitrile rubber NBR
sleeve:
as selected

CAD data

size 50         dxf / stp
size 65         dxf / stp
size 80         dxf / stp
size 100       dxf / stp
size 125       dxf / stp
size 150       dxf / stp
